Unlike batch manufacturing, where drug substances or finished products are made with separate unit manufacturing steps with intermediate storage and testing between steps that sometimes take place in different global manufacturing locations, continuous pharmaceutical manufacturing allows each element of manufacturing to take place in a continuous process in a single facility. This compresses the manufacturing time, improves quality, reduces costs, and increases overall efficiency.

As highlighted in FDA’s March 2023 continuous manufacturing guidance (1), the concept of continuous manufacturing is particularly well suited for downstream processing for biopharmaceutical production and the manufacture of solid oral dosage forms. As the order of 60% of the sales volume of drug products continues to be solid oral dosage forms, this technology review will concentrate on the manufacture of compressed tablets and powder-filled capsules, where the batching, milling, mixing, tablet compression, or filling of dry powders in capsules applies more to dry (water-free) process equipment cleaning over the more common wet cleaning.

Industry and regulatory obstacles to dry cleaning implementation and risk mitigation

Although regulatory agencies such as FDA support the transition from batch to continuous manufacturing, the pharmaceutical industry has been slow to embrace this change. A self-audit of the sparse history of continuous manufacturing submission, review, and approval point to FDA not being the major obstacle to the transition (2). FDA’s Center for Drug Evaluation and Research (CDER) published a draft guidance in 2019 outlining quality considerations for continuous manufacturing (3). Earlier in 2014, CDER stablished the Emerging Technology Program (ETP), a collaborative program where industry representatives can meet with Emerging Technology Team (ETT) members to resolve potential technical and regulatory issues around the development and implementation of a novel technology prior to filing a regulatory submission. Examples of ETP-accepted emerging technologies in 2022 are continuous manufacturing of small-molecule drug substances and drug products and continuous manufacturing for biological molecule downstream processing.

Among the regulations pertinent to cleaning during continuous manufacturing is

211.67), “Equipment Cleaning and Maintenance” (4), which states that documentation should include:

responsibility for equipment cleaning and maintenance

a detailed description of the cleaning procedure

In addition, the 2016 FDA Guidance for Industry Q7

Good Manufacturing Practice Guidance for Active Pharmaceutical Ingredients

Equipment maintenance and cleaning (Section 5.2).

Written procedures should be established for cleaning equipment and their subsequent release for use in the manufacture of intermediates and APIs. Cleaning procedures should contain sufficient details to enable operators to clean each type of equipment in a reproducible and effective manner. These procedures should include the following (Section 5.21):

assignment of responsibility for cleaning of equipment

cleaning schedules, including, where appropriate, sanitizing schedules

a complete description of the methods and materials, including dilution of cleaning agents used to clean equipment

when appropriate, instructions for disassembling and reassembling each article of equipment to ensure proper cleaning

instructions for the removal or obliteration of previous batch identification

instructions for the protection of clean equipment from contamination prior to use

inspection of equipment for cleanliness immediately before use, if practical

establishing the maximum time that may elapse between the completion of processing and equipment cleaning, when appropriate” (5).
