David A. Wyatt is chief operating officer at Aston Particle Technologies Ltd., Aston University, Birmingham, United Kingdom.

David A. Wyatt

Particle surface modification is becoming a vital strategy in the pharmaceutical industry for “difficult to formulate” APIs. Most surface modification techniques, however, alter innate particle properties either chemically or physically. These surface modification technologies involve the use of elevated temperatures, high pressures, and/or solvents, making these processes highly unsuitable for unstable APIs that are degraded when exposed to such conditions.

	Aston Particle Technologies (APT) has developed the world’s first aerosolized dry particle coating technology. This technology is a one-step, ambient temperature process, with controlled processing parameters that can deliver repeatable product performance with commercially available excipients.

	The science underpinning this technology requires the use of a high G-force chamber, with a curtain of nitrogen gas to fluidize the powder at the chamber wall, which disperses any agglomerated fine or coarse particles. The co-aerosolization of the particles results in coating of all the fine particles onto the surface of the coarse particles and can produce particles with designed functionalities, even with highly sensitive APIs. These functionalized particles enhance the inherent properties of API without degrading them in any way. There is no exposure to heat/solvent, and the particles suffer no attrition during processing, which is a significant advantage compared with other current state-of-the-art dry coating technologies (1-5) (

	The difference in this technology is that blending occurs through particle-particle interaction in the aerosolized state compared to traditional solid-solid interactions of technologies such as high-shear blending. The intimate contact of “clouds” of individual particles facilitates the attachment of all the fine particles onto the surface of the coarse particles without causing undesirable physical/chemical modification to the constituent particles.

	The principle of dry coating with APT’s technology arises from the difference in particle size between the host and carrier. Under normal mixing of a binary blend of fine and coarse particles, the fine particles display high levels of cohesivity, which can lead to the formation of agglomerates or to segregation, producing non-homogeneous mixes in an “interactive mix” (3, 4, 6-9). Dry particle coating overcomes the high cohesive forces associated with the fine “guest” particles with the fines becoming uniformly bound to surface of coarse “host” particles by strong forces of adhesion. This principle holds true as long as the size difference between the guest and carrier particles is at least double. Coating occurs because the forces of attraction between fine and coarse are greater than the weight of the fine particle itself (3, 4, 6, 10-12).

	Dry coating using the technology can be depicted in three primary stages (

), which occur simultaneously: firstly, the dispersion of all the agglomerates of both the fine and coarse particles through application of the high G-force generated by revolving the processing chamber at high speed, balanced by the injection of nitrogen gas into the chamber; secondly, the dispersal of the fine particles around the coarse particles; and finally, the attachment/adhesion of the fine particles to the surface of the host, reaching a uniform spatial distribution of the fine particles.

	Powders generated by APT’s dry coater at both laboratory and pilot scale have demonstrated proof of concept for various formulation applications, including blends for dry powder inhalers (DPI), API solubility enhancement, and modification of dissolution rate. Scanning electron microscopy (SEM) and confocal laser scanning microscopy (CLSM) images of the coarse host particles loaded with the fine guest material are shown in


	The SEM micrographs show that the fine de-agglomerated guest material is coating the coarse carrier as individual particles. These images also show that there is no free or unbound fine material and that the host particles appear to have mopped up all the available fines in the field of view.

	Additionally, the CLSM micrographs confirm that the larger particles can be completely dry coated with finer material using APT’s dry coating technology. In the case shown in

, micronized, fluorescent rhodamine particles have been dry coated onto non-fluorescent microcrystalline cellulose (MCC). The cross-sectional images demonstrate that the microfine rhodamine particles form a coherent coating on the surface of the MCC host.

	Blend investigations demonstrate that this dry coating principle can generate highly ordered blends, using different APIs and excipients, with reproducibly tight content uniformities. Even at concentrations as low as 0.5% w/w, the relative standard deviation (RSD) is consistently <2% with good API recovery of typically >98% (see

	For consistent dose performance, the pharmaceutical industry typically requires blend concentration RSD to be <6% (13). This requirement is particularly crucial for inhaled formulations in which the therapeutic dose is often in the microgram range. Through optimized process development, a platform for the application of the technology to a DPI formulation has been registered as APT-Hale.

	The controlled nature of the APT-Hale process for DPIs leads to consistent API delivery, which means that the technology also determines the dosing performance of the formulated blend. The technology produces tight content uniformity and can also be tuned to deliver a particular fine particle fraction (FPF) as demonstrated in

, where a single-blend formula processed in a designed set of experiments has been “dialed up” to deliver increasing FPF. The strength of adhesion between the fine and coarse particles can be controlled, thereby determining the amount of API that will detach from the carrier when tested in the Next Generation Impactor. Because the blends carry little or no electrostatic charge, they can be handled immediately after processing and require no conditioning or quarantine period.

	To demonstrate the potential of the technology in respiratory medicine development and manufacture, a series of designed experiments, using a QbD approach, has been completed with two different, commercially sourced lactose carriers. The object of these experiments was to optimize an API/lactose formulation based on key critical quality attributes. Optimizing time and rotation speed of the blending process, which were identified as critical process parameters, demonstrated that the carrier influences the processability of the formulation (see

). The resultant design space enables the formulator to visualize a manufacturing control space for a formulation using either carrier.

	Although many of these experiments were carried out at laboratory scale, APT recently collaborated with the automation engineering team at GB Innomech, which has designed and developed a system to scale up the technology 100-fold. The system has been designed so that operators can quickly access and store the required process conditions for specific production batches. Operational qualification at this pilot scale is ongoing but the process is proving to be completely scalable.

, 413 (1) 36-43 (2011).
	2. Q.T. Zhou et al.,

European Journal of Pharmaceutical Sciences

, 40 (5) 412-421 (2010).
	3. T. Ishizaka et al.,

, 36 (7) 2562-9 (1988).
	4. T. Ishizaka et al.,

, 41 (6) 361-8 (1989).
	5. L.E. Beach, Effect of Dry Particle Coating on the Properties of Cohesive Pharmaceutical Powders, Dissertation, Otto H. York Department of Chemical, Biological and Pharmaceutical Engineering (New Jersey Institute of Technology: New Jersey, May 2011).
	6. E.Z. Dahmash and A.R. Mohammed,

, 12 (12) 1867-1879 (2015).
	7. J.A. Hersey,

, 11 (1) 41-44 (1975).
	8. C.W. Yip and J.A. Hersey,

, 16 (2) 189-192 (1977).
	9. H. Honda et al.,

Colloids and Surfaces A: Physicochemical and Engineering Aspects

, 82 (2) 117-128 (1994).
	10. R. Pfeffer et al.,

, 117 (1-2) 40-67 (2001).
	11. V.A. Saharan and P.K. Choudhury,

, 61 (3) 323-34 (2011).
	12. L.J. Jallo et al.,

 (United States Pharmacopoeial Convention, Rockville, MD,
	2017).


	Vol. 42, No. 3
	March 2018
	Pages: 26â30

	When referring to this article, please cite it as J. S. Koner,

, "Dry Particle Coating-A Unique Solution for Pharmaceutical Formulation,"

 is chief technical officer, a.u.r.mohammed@aston.ac.uk, all at Aston Particle Technologies Ltd., Aston University, Birmingham, United Kingdom. Afzal Mohammed is also a professor and chair in pharmaceutics at Aston Pharmacy School, Aston University, Birmingham, United Kingdom.

	*To whom all correspondence should be addressed.

Articles

Aston Particle Technologies has developed a technology that produces functionalized particles in a one-step, environmentally friendly process.
